Sản phẩm của Trí Việt

VPS Static Balancing Valve, DN15 to DN300
Y-pattern  valves  having  characterized  throttling  disk  tend  towards  equal percentage performance,  fitted with  Integral square edged entrance orifice plate and  insertion  test points. Double  regulating  feature allows valve  to be set with an Allen key. Operation of  the valve  is by means of  the Microset hand wheel. All valves operate  from close  to  fully open with  complete  turns of  the handwheel. The digit in the outer window indicates tenths of a turn
DN65 to DN150 valves operate  from close  to  fully open with 8 complete  turns of the handwheel, 12 turns for DN200 to DN250 and 18 turns for DN300 . The digit in the outer tenths of a turn.
Model Number :
VPS015-C, VPS020-C, VPS025-C, VPS032-C, VPS040-C, VPS050-C, VPS065-C, VPS080-C, VPS100-C, VPS125-C, VPS150-C, VPS200-C, VPS250-C, VPS300-C

VPF series Motorized dynamic balancing valve for FCU DN15 TO DN25
Motorized dynamic balancing valves are used  in FCU  system or as  zone valve control. VA-7078-23 actuator  is used with VPF  series balancing valve for On/Off control of the fan coil unit and the flow range is 0.43 - 1.76m3/h
Rated Pressure 25bar, Close-off Pressure 250kPa, 230 VAC ±10%(50/60 Hz)
Model Number :
VPF015L02-C, VPF020L02-C, VPF020L04-C, VPF020H06-C, VPF020H08-C, VPF025L04-C, VPF025H06-C, VPF025H10-C

VPD Constant Flow Rate Dynamic Balancing Valve DN15 TO DN40
The VPD dynamic balancing valves are designed as a constant flow valve which provides easy and reliable balancing of the system, regardless of any fluctuations in the differential pressure of the system. Common applications for dynamic balancing valve includes terminal unit or branch balancing, air handling unit flow control in common HVAC system, multiple chillers or pump balancing system in high-rise buildings
Model Number :
VPD015L01-C, VPD020L04-C, VPD025L03-C, VPD032L10-C, VPD040L14-C

Pressure Independent Balancing and Control Valve - VPA series Dynamic Balancing Valve
and VAP Actuator DN25...150, PN16.
Pressure  Independent Balancing and Control Valve  includes  two  functional control elements: Dynamic Balancing Valve and Motorized
The built-in balancing tube has more compact structure and can avoid damages during shipping and installation compared to the external
Model Number :
VPA025-C, VPA032-C, VPA040-C, VPA050B-C, VPA050-C, VPA065-C, VPA080-C, VPA100-C, VPA125-C, VPA150-C, VAP500-24-C, VAP1000-24-C, VAP3000-24-C

The VF6000 Series Butterfly Valve and VA300/VA200 Actuator shut off or regulate the flow of hot or chilled water in a HVAC system.
This series covers models from DN50 to DN1000 with either on/off or modulating output via various actuators
Model Number :
VF6461xx-C , VF6431xx-C, VA9320 , VA9335, VA301xxx-C, VA302xxx-C, VA303xxx-C , VA304xxx-C, VA305xxx-C , VA306xxx-C, VA307xxx-C, VA308xxx-C, VA309xxx-C, VA310xxx-C, VA311xxx-C, VA312xxx-C

VF3000 series Butterfly Valves and VA5000 series Electric Actuators
DN50...1000, PN16.
The VF3000 series butterfly valves are used for shutting off or regulating the flow of hot or chilled water in a HVAC system. Mounted with VA5000 series actuators, the valves operate with a wide range of applications, including two-position and
Model Number :
VA5003xxx-C, VA5005xxx-C, VA5008xxx-C, VA5020xxx-C , VA5040xxx-C , VA5060xxx-C , VA5080xxx-C , VA5100xxx-C , VA5170xxx-C, VA5230xxx-C, VA5350xxx-C, VA5500xxx-C, VA5800xxx-C

DN50...1000, PN16.
The VF3000 series manual butterfly valves are designed to manually shut off or modulate the flow of hot or chilled water in HVAC system.Medium Hot / chilled water, glycol solution (＜50% concentration) in HVAC system Medium temperature -10℃~120℃ Valve Body Ductile iron (GGG40) Stem Stainless steel Valve disc Ductile iron (GGG40) with Nylon 11 coating or Stainless steel (SS304)
Model Number :
VF3461xx-MC , VF3431xx-MC

M9310 / VA9310 Series Electric Non-Spring Return Actuators
The M9310/VA9310 Series Electric Non-Spring Return Actuators provide control of dampers in HVAC also control of valves with ISO Flange mounting such as VG1000 valve. All actuators in this series provide 88 lb·in (10 N·m) rated torque
Automatic Signal Input Detection, On/Off, Floating, and Proportional Control with Adjustable Span and Offset. 100,000 Cycles and 2.5 Million Repositions
Model Number :
M9310-HGA-3, VA9310-HGA-3, VA9308,VA9310, VA9316, VA9320,VA9335

M9108 / M9116 Series Damper Actuators
Simple direct coupling reduces installation and commissioning time while improving reliability by eliminating damper linkages .Robust 70 lb-in (8 Nm / 16Nm) torque rating
On-off, floating and proportional control inputs meet the needs of most applications
Output position feedback provides simple closed-loop control with accurate position  sensing
Model Number :
M9108-AGA-2 , M9108-AGC-2, M9108-AGD-2 , M9108-AGE-2 , M9108-GGA-2, M9108-GGC-2 , M9108-HGA-2, M9108-HGC-2 , M9108-JGA-2 , M9108-JGC-2
M9116-AGA-2 , M9116-AGC-2, M9116-AGD-2 , M9116-AGE-2 , M9116-GGA-2, M9116-GGC-2 , M9116-HGA-2, M9116-HGC-2 , M9116-JGA-2 , M9116-JGC-2


M9106 / M9109 Series Damper Actuators
Simple direct coupling reduces installation and commissioning time and improves reliability by eliminating damper linkages. Single screw coupling provides three-point shaft gripping
•   Designed for zone damper and ball valve actuator applications
•   Small, compact design — allows installation in tight-fitting locations
•   Rotation range adjustable 30 to 90 degrees CW or CCW
Model Number :
M9106-AGA-2, M9106-AGC-2, M9106-AGF-2 , M9106-GGA-2, M9106-GGC-2 , M9106-IGA-2 , M9106-IGC-2, M9109-AGA-2 , M9109-AGC-2 , M9109-GGA-2, M9109-GGC-2

VA-7310 Electric Valve Actuator
The VA-7310 electric valve actuator is available with 3-point (floating), 3-point with feedback signal or proportional control. These actuators are available with 100 N and 150 N nominal force. They can be used in combination with the: VB-5040-S, VB-5030, VB-7040 and VG7000 series valves

Model Number :
VA-7310, VA-7313, VA-7314, VA-7315, VA-7311, VA-7312

The VA-715x Series synchronous, motor-driven actuator provides incremental (three-wire), incremental with feedback, or proportional control of valves with up to 3/4 in. stroke in heating, ventilating, and air conditioning applications.
The VA-720x Series Electric Actuator provides incremental or proportional control of valves with up to a3/4 in. stroke in heating, ventilating, and air conditioning

Model Number :

VA-7150-1001, VA-7153-1001, VA-7152-1001, VA-7200-1001, VA-7203-1001, VA-7202-1001, VA-7242-1001

The VA-7010 Series Electric On/Off Actuators provide two-position (open/closed) control and can easily be field mounted with a threaded coupling onto VG5000 Series Forged Brass Valves. Refer to the VG5000 Series Forged Brass Valves 1/2 Through 1 in., Two-Way Normally Closed and Three-Way.
The VA-7010 actuator features a manual operating lever (shown in Figure 3) for manually opening Normally Closed (N.C.) valves or the N.C. port of 3-way valves. The lever will not fully close Normally Open (N.O.) valves or the N.O. port of 3-way valves
Model Number :
VA-7010-8001, VA-7010-8002, VA-7010-8003, VA-7010-8006, VA-7010-8007

VA-748x Electric Valve Actuators
VA-748x Series Electric Valve Actuators provide floating or proportional control in HVAC applications. The compact design of this actuator series makes it ideal for installations in confined locations, such as fan coil applications
The VA-748x Series Actuator is designed for field mounting onto the terminal unit valves
made by Johnson Controls .
Model Number :
VA-7480-0312, VA-7482-0312, VA-7482-8002-RA, VA-7482-9002-RA

VA-7700 Series Electric Valve Actuators
The VA-77xx Series synchronous motor driven actuator, for valves in heating, ventilation and air conditioning applications, is available for floating (3-point) control or proportional control
with 0-10 V position feedback signal.
The actuator can be combined with VG7000, VG9000 and VGS8… valves
non spring return actuator has a 500 N nominal force and responds to a variety of input signals
Model Number :
VA-7700-1001, VA-7700-1003, VA-7740-1001, VA-7740-1003, VA-7706-1001, VA-7746-1001

The RA-3000 series synchronous motor-driven reversible actuators are available for 3-point
(floating) or with electric positioner for 0…10 V control. They feature factory calibrated pressure
switches to provide specified close-off ratings. These actuators are available in three sizes with
1600 N, 1800 N and with 3000 N nominal force and can be used with JC flanged valves according to maximum close-off pressure ratings specified

Model Number :
FA3341-7416
