Bộ Điều Khiển DDC Cấp Mạng

The N30 Supervisory Controller is designed to monitor and supervise Heating, Ventilating, and Air Conditioning (HVAC) equipment as well as lighting, security, and building access.
The N30 efficiently supervises the networking of Application Specific Controllers (ASCs) and provides building automation features
Model Number :
MS-N301010-1 Supervisory controller, base unit with N2 field bus
MS-N301012-1 Supervisory controller, base unit with N2 field bus, and Local Display Terminal (LDT)
MS-N301310-1 Supervisory controller, base unit with N2 field bus and Ethernet peer bus
MS-N301312-1 Supervisory controller, base unit with N2 field bus, Ethernet peer bus, and Local Display Terminal (LDT)

NCM300 Network Port is a configurable gateway between Metasys® and a system using Allen- Bradley’s Data Highway Plus communications protocol. It is a bidirectional interface device that can act as a subordinate, peer, or master. Through Network Port
Model Number :
NU-NCM350-8 Network Port (using NCM350)
NU-NCM300-701 Network Port (repair)

The NCM45x0-2 Series Network Control Module is a fully user-programmable supervisory controller.
It is responsible for monitoring and controlling networks of field-level building automation devices and Heating, Ventilating, and Air Conditioning (HVAC) equipment
Model Number :
MS-NCM4510-2 Supports one N2 trunk (RS-485 port). Up to 100 devices (60 to 200 TC-9100s) are supported on the N2 trunk with the use of a repeater
MS-NCM4520-2 Includes a LONWORKS port and supports one LONWORKS trunk. Up to 127 devices are supported on the LONWORKS port.

The Metasys® system extended architecture N1 Network Integration Engine (NIE) connects existing Metasys N1 based building automation systems into the new generation of technology that includes the Internet, Information Technology (IT), and enterprise level global communication. Metasys system extended architecture N1 Integration is based on the NIE, a
Web-enabled network controller that speaks IT and Internet language to the expanding world of Web browsers and remote operations centers. At the same time, it uses Internet Protocol (IP) Ethernet network technology to communicate with Metasys N1 networks that are installed in many facilities worldwide.
Model Number : MS-NIE8500-0 , MA-NIE8500-1, MS-NIE5510-0 , MS-NIE5510-0U , MS-NIE5511-0 , MS-15KUPG-0


The Metasys® system extended architecture N1 Network Integration Engine (NIE) connects existing Metasys N1 based building automation systems into the new generation of technology that includes the Internet, Information Technology (IT), and enterprise level global communication. Metasys system extended architecture N1 Integration is based on the NIE, a
Web-enabled network controller that speaks IT and Internet language to the expanding world of Web browsers and remote operations centers. At the same time, it uses Internet Protocol (IP) Ethernet network technology to communicate with Metasys N1 networks that are installed in many facilities worldwide.
Model Number : MS-NIE8500-0 , MA-NIE8500-1, MS-NIE5510-0 , MS-NIE5510-0U , MS-NIE5511-0 , MS-15KUPG-0


Network Control Engines (NCEs) provide supervisory control of a specified field bus trunk with up to 32 field controllers. Depending on the model, an NCE supports either a BACnet® Master-Slave/Token-Passing (MS/TP) trunk, an N2 Bus trunk, or a LONWORKS® network trunk.
All NCE models feature 33 integral I/O points and a Sensor/Actuator (SA) Bus, which allow you to increase the NCE's I/O field point capacity and also integrate NS Series Network Sensors and variable-frequency drives (VFDs) into your NCE application
Model Number : MS-NCE2500-0 , MS-NCE2506-02 , MS-NCE2510-0 , MS-NCE2511-0 , MS-NCE2516-0 , MS-NCE2517-0 , MS-NCE2520-0 , MS-NCE2521-0 , MS-NCE2526-0 , MS-NCE2527-0 , MS-NCE2560-0 , MS-NCE2560-0U , MS-NCE2561-0 , MS-NCE2566-0 , MS-NCE2567-0

The Metasys SNE series network engines and SNC series network control engines are Ethernet-based, supervisory controllers that connect Building Automation System (BAS) networks to IP networks. Supports connectivity to open network standards for complete flexibility in the selection of field devices. They include BACnet/IP, BACnet MS/TP, N2 Bus, LonWorks, Modbus TCP/IP, Modbus RTU, M-Bus, KNX, Zettler Fire Panel, Tyco C•CURE, victor, and other third-party protocols.
Model Number : M4-SNE22000-0 , M4-SNE22001-0 , M4-SNE11000-0 , M4-SNE11001-0 , M4-SNE10500-0 , M4-SNE10501-0 , M4-SNE110L0-0 , M4-SNE110L1-0 , SNC25150-0 , SNC25151-0 , SNC25151-0H , SNC25150-04 , SNC25151-04, SNC25151-04H , SNC16120-0 , SNC16121-0 , SNC16121-0H , SNC16120-04, SNC16121-04 , SNC16121-04H

The BACnet® Router facilitates communication between BACnet IP and BACnet Master-Slave/Token-Passing (MS/TP) networks to monitor and control a wide variety of HVAC equipment, meters, fire alarm panels, and lighting on the Building Control Management (BCM) system. Efficient router for use with the BCM Workstation to route messages
between BACnet MS/TP and BACnet IP
• Support for up to 100 PCx MS/TP field devices (or 64 non-PCx MS/TP field devices) under a single router
• Support for the integration to the BCM Workstation so that router configuration can be done by logging into the Workstation. This allows all routers to be configured from a single login.
• Basic diagnostics provided

Network Automation Engines (NAEs) provide comprehensive equipment monitoring and control, through key features such as scheduling, alarmand event management, energy management, data exchange, data trending, and data storage. These tools help reduce
operation and energy costs for any type of building. This line of NAEs features and leverages IP connectivity and web-based access to Metasys® Building Management Systems, including the BACnet® protocol, the LONWORKS® network, and the N2 Bus protocol, to monitor and supervise a wide variety of HVAC, lighting,security, and fire safety equipment.
Model Number : MS-NAE3510-2,  MS-NAE3510-2U , MS-NAE3511-2 , MS-NAE3514-2 ,
MS-NAE3515-2 , MS-NAE3520-2 , MS-NAE3521-2 , MS-NAE3524-2, MS-NAE3525-2
MS-NAE4510-2 , MS-NAE4510-2U , MS-NAE4511-2 , MS-NAE4520-2 , MS-NAE4521-2 , MS-NAE451L-2
MS-NAE5510-2 , MS-NAE5510-2U , MS-NAE5511-2 , MS-NAE5520-2 , MS-NAE5521-2
MS-NxE85SW-0 , MS-NxE85SW-61


Support BACnet MSTP client/server, BACnet IP client/server, Modbus RTU host/slave, Modbus TCP host/slave, MQTT, SOX protocols
Support peer-to-peer (P2P) functions, compatible with EC and CW controllers
Built-in HTML5 Web server and SSL certificate support, Provide RESTful apis and Web services, Support Network Time Protocol (NTP) client
Support SMTP protocol with SSL authentication (send email)
Built-in Johnson patent adaptive PID PRAC+, PVDC, Sequencer and other algorithms
Model Number : EC-1208 ; EC-1616


The FS is a high-performance network controller with HTML5 graphics, BACnet MSTP Client/Server, BACnet IP Client/ Server, Modbus RTU M/S, Modbus TCP M/S, MQTT, TCOM, SOX, RESTful API and graphics web services
• Built-in VPN Server and Client
• Network Time Protocol (NTP) Client
• SMTP protocol with SSL authentication
• SQL Lite up to 100,000 records
• Built-in dashboard
Model : EASYIO-FS-20 ; EASYIO-FS-32


The Facility Explorer SNC series (F4-SNC) are Ethernet-based, supervisory controllers that connect Building Automation System (BAS) networks to IP networks. The SNC features onboard inputs and outputs for direct control of equipment. This device monitors and controls networks of field-level building automation devices, including HVAC equipment, lighting, security, and fire safety equipment.
Protocol: BACnet MS/TP, BACnet IP, Modbus RTU, Modbus TCP, LonWorks, M-Bus, EIB/KNX
Model :
SNC25150-0, SNC25150-04, SNC16120-0, SNC16120-04, SNC25152-0, SNC25152-0H, SNC25152-04, SNC25152-04H, SNC16122-0, SNC16122-0H, SNC16122-04, and SNC16122-04H, SNC25151-0, SNC25151-0H, SNC25151-04, SNC25151-04H, SNC16121-0, and SNC16121-04

The FX80 Supervisory Controller is a web-based supervisory-class controller in the Facility Explorer® product family. The FX80 controller manages networks of field controllers using open communication protocols

Johnson Controls® N2 (exclusive to FX80) BACnet MS/TP BACnet IP Client and Server

Modbus® Remote Terminal Unit (RTU) Client an Server

Modbus Transmission Control Protocol (TCP) Cl and Server

LonWorks FTT-10A (requires LonWorks communication module)

LonWorks over IP / M-Bus / EIB/KNX / Simple Network Management Protocol (SNMP)

MODEL: FX-SC8BDWIFI-0 / FX-SC9BASE-0
