Hệ Thống An Ninh Vào Ra (Access Controls)

S300-DIN-RDR8 / S300-DIN-I32O16  DOOR CONTROLLER
The S300-DIN-RDR8S module provides interface control for access and security devices associated with up to eight doors.
The I32O16 module supports 32 inputs, 16 relay outputs, and 16 open collector outputs. Both RDR8S and I32O16 use standard RS-485 communications and can interface with the following controllers:
• CK722
• CK721-A version 3.0 and higher
Model Number :
S300-DIN-RDR8


BỘ ĐIỀU KHIỂN 2 CỬA  – JOHNSON CONTROLS
S300-DIN-RDR2SA / S300-DIN-I8O4 DOOR CONTROLLER
The S300-DIN-RDR2SA module provides interface control for access and security devices associated with up to two doors. The S300-DIN-I8O4 module supports 8 inputs, 4 relay outputs, and 4 open collector outputs. Both the RDR2S-A and I8O4 modules use standard RS-485 communications and can interface with the following controllers:
• CK722 / CK721-A / CK721 / CK720/CK705
Model Number :
S300-DIN-RDR2SA


The CK722 is a powerful and flexible network controller for the Johnson Controls® P2000AE Security anagement System (SMS).
CK722 controllers to be connected via Ethernet; total system capacity is 2,048 doors per P2000AE server
CK722 controller — support up to 32 field devices per bus, for a maximum of 64 field devices per controller
The following devices are supported on the S300 buses:
• Legacy S300 field devices (S300-RDR2, S300-I16, S300-IO8, S300-SIO8, and S300-SI8)
• S300-DIN-RDR2S
• S300-DIN-RDR8S and S300-DIN-I32O16
• S300-DIN-RDR2SA and S300-DIN-I8O4
• S300-KDM (Keypad/Display Module)
Model Number : CK722


NETWORK DOOR CONTROLLER– JOHNSON CONTROLS
S321-IP 2 DOOR CONTROLLER
The CK721-A is an advanced, intelligent, network controller capable of handling high volume, high-speed traffic with host security management systems.
Each CK721-A can support up to 64 readers;  however, total capacity is 2,048 readers in a standard P2000
Model Number : CK721-A


S321-IP 2 DOOR CONTROLLER
Up to 2 readers per controller
Embedded 16-bit processor
4 MB flash memory, 10/100Base-T network connection
Storage capacity for up to 5000 cardholder badges
Accepts up to 128-bit badge numbers
40 holidays, 64 schedules
2 schedules per badge
Model Number : S321-IP


Housed in a powder-coated MS cabinet, with rugged 5Amp power supply, very compact 2-door One EAC supports up to 16 floors including the ground floor and the basement. An extra EAC panel can be attached to the current one for expansion of 52 floors via an FRC connector.
RTCNon volatile real time clock calendar, Data retention for 10 years without external power
Keypad12 keys membrane keypad for local programming
8 bit micro controller running @42 MHz / 128 Kbytes / 2 MB flash
Model Number : XS-3S


Housed in a powder-coated MS cabinet, with rugged 5Amp power supply, very compact 2-door access control system with a high-speed 32-bit processor and large storage of 16GB. It has a capacity to store 250,000 cardholder database and buffer for last 500,000 events
supports 2 doors and 4 access readers where the controller can be configured as Standalone/Master/Slave. It supports a host of other rule-based features apart from global anti-pass back

Model Number : XS-3S

2 DOOR BACnet CONTROLLER
 Native PoE/PoE+
 2 door 4 reader (2 doors with IN/OUT readers)
 RJ45 reader connection
 True Plug and Play operation
 Advanced diagnostic LEDs
 BACnet open protocol
 Optional metal cabinet and PSU,  Battery backup
Model Number : DC-0003IP

The CEM Systems DCM 400 (Door Control Module) is an intelligent four-door controller designed to directly interface CEM Systems AC2000 access control system (version 10.2 and higher) with Wiegand or CEM Systems approved and supplied Open Supervised Device
Protocol (OSDP v2) smart card readers
Using powerful 32-bit processors, the DCM 400 gives full off-line verification and decision making at the point of entry, even when host communication is not available.
Model Number :
DCM/400/004, DCM/400/104, DCM/400/114, DCM/400/124, DCM/400/134

The CEM Systems DCM200 (Door Control Module) is an
intelligent two-door controller designed to be highly secure and directly interface with CEM Systems AC2000 access control software (version 10.2 and higher). It also supports up to four Wiegand or CEM Systems approved Open Supervised Device Protocol (OSDP v2) smart card readers. These OSDP compliant readers can be used (Entry/Exit configuration) for bi-directional control on two doors.
Model Number :
DCM/200/002, DCM/200/102, DCM/200/112

IP-ACM v2 2-Reader Ethernet Door Module
Up to 32 IP-ACMs per iSTAR Ultra and iSTAR Ultra SE, and up to 8 per iSTAR Ultra LT1.
Convenient second port for biometric reader or efficient network diagnostics
10/100/GigE connectivity / PoE or PoE Plus
Full duplex RS-485 on board to leverage future technology
OSDP support fosters device interoperability
Model Number :
IP-ACM2A-MB, IP-ACM2A-EM, IP-ACM2A-EP, IP-ACM2-CAN, IP-ACM2-CAN-P, IP-ACM2A-MB-5PK

16 /32 READER DOOR CONTROLLER
iSTAR Ultra uniquely combines support for traditional hard-wired access control doors with support for wireless lock sets, all in the same controller. Up to 32 readers are supported by the iSTAR Ultra, of which the total can be comprised of readers from ACM access control modules, IP-ACMs and/or wireless locksets.iSTAR Ultra uses a General Controller Module (GCM) which includes standard 2GB RAM and 16GB SD card for memory, and has two onboard gigabit network ports for reliable network communications. The GCM controls up to four ACMs, with each ACM supporting up to eight Wiegand, RM or OSDP readers, along with 24 supervised inputs and 16 outputs which can be individually wet- or dry-configurede
Model Number :
USTAR008, USTAR016, USTAR-GCM, USTAR-ACM, USTAR-CAN, USTAR-GCM-2U, USTAR-ACM-4U

Istar Ultra LT is a powerful, network-ready door controller that supports up to 16 readers, using IP-ACM Ethernet Door Modules. Its strong feature set answers. The most demanding access control requirements of enterprise applications. Onboard 256-bit AES network encryption Enables wireless locks to communicate with    C•CURE 9000 providing a fully integrated and managed lock solution Utilizing Istar Ultra LT, wireless locks from ASSA ABLOY and Schlage1 communicate with C•CURE 9000 providing a fully integrated and managed lock solution
Model Number :
USTAR-LT08-EM, USTAR-LT08-EP, USTAR-LT08-MB, USTAR-LT16-EM, USTAR-LT16-EP, USTAR-LT16-MB

iSTAR Edge One-,Two- or Four-Reader IP Edge Device) Optional Power over Ethernet (PoE) module features PoE Plus with enough power for two doors and associated devices
AES 256 network encryption;    FIPS 197 listed
Types of Readers Supported. Wiegand and    RM (RM only for readers 3 and 4) Reader Technologies
Up to 32 additional inputs using I8 input modules on RM bus (64 additional with 4-reader model)
Model Number :
ESTAR001, ESTAR001-POE1, ESTAR001-MB, ESTAR001-MBP, ESTAR002, ESTAR002-POE1, ESTAR002-MB, ESTAR004, ESTAR004-RM, ESTAR004-MB

KT-4 Encrypted 4-Door Controller using EntraPass can be configured in two user-friendly operational modes. KT-4’s Standalone Mode offers basic door security using a simple web browser without the need to connect to a host system. Alternatively, KT-4 can be used with the powerful EntraPass Security Management Software to provide more advanced and fully integrated access control features.
The KT-4 four-door controller is a cyber-resilient and easy-to-use networked access control solution with support for up to eight ioProx XSF and ioSmart readers/cards (4 doors IN/OUT control)
The KT-4 allows expansion modules to add up to 256 inputs or to add up to 256 outputs such as relays and drain outputs
Model Number :
KT-4, KT-4-PCB, KT-4-WIFI, KT-4-PoE

KT-2 Ethernet-ready two-door controller supports four readers and can be configured in two user friendly operational modes. The KT-2 Standalone Mode offers basic two-door security
using a simple web browser without the need to connect to a host system. Alternatively KT-2
can be used with the powerful EntraPass Security Management Software to provide more
advanced and fully integrated access control features such as Wi-Fi connection. Utilizing the
built-in Wi-Fi antenna reduces installation time and costs while providing an ideal solution for
projects with challenging infrastructure designs that would require extensive cabling
Model Number :
KT-2-M, KT-2-BP, KT-2-MP, KT-2-CAB-M, KT-2-PCB, KT-2-PCB-RETRO
