Hệ Thống An Ninh Camera

Supports 64-ch high definition network video input and storage
Supports H.265/H.264 video format, Supports 2-ch HDMI and 1-ch VGA output, with HDMI1 up to 4K(3840×1080P/60Hz) resolution Max 500Mbps incoming bandwidth. Supports 16-channel 1080P video real-time decoding and
synchronous playback. Supports 16 SATA hard disk ports and each supports a hard disk with capacity up to 6TB . Support HDD hot swap

Supports 32-ch high definition network video input and storage
Supports H.265/H.264 video format
Supports 2-ch HDMI and 1-ch VGA output, with HDMI1 up to 4K(3840×1080P/60Hz) resolution. Max 384Mbps incoming bandwidth. Supports 16-channel 1080P video real-time decoding and synchronous playback
Supports 16 SATA hard disk ports and each supports a hard disk with capacity up to 6TB
Support HDD hot swap with Raid 5

Redundant X-Series exacqVision NVR with 8 IP Professional or Enterprise licenses (200 max), Up to 288TB RAID configured storage (Up to 240TB usable).

Linux Ubuntu 22.04 LTS or Windows Server 2022 OS on Dual SSD RAID1, redundant power supplies, 32GB RAM, Dual 1GbE on-board + Dual 10GbE SFP NIC, 3 x USB, 1 x VGA, iDRAC9 Enterprise remote management, Pre-installed exacqVision VMS software

IP Desktop 16 port PoE+ G-Series exacqVision NVR with 16 IP licenses (16 max). Up to 12TB Internal storage. PoE 240W total, 15w simultaneous all ports, 30w max per port.

Linux Ubuntu 22.04 LTS OS on SSD, 4GB RAM, 1 X 1GbE, 1 x 2.5GbE, 6 x USB, 1 x HDMI, 1 x DVI.

Includes mouse with on-screen keyboard.

Pre-installed exacqVision VMS software

2.0 Megapixel Starlight WDR Intelligent IP Dome Camera
nbuilt 33X HD integrated camera module 1/2.8" progressive scanning CMOS sensor
ICR infrared filter type automatic switch to realize true day/night surveillance
Starlight-level ultra-low illumination: 0.0005 lux , Supports multi-frame composite pattern wide dynamic and the maximum dynamic range is 120dB
HD network video output: 1920x1080@60fps

HD 2MP IR IP Fixed Camera
1/2.8" progressive scan CMOS sensor Built-in dot matrix IR illuminators, covering up to 30
meters at 850nm wavelength.
High-resolution image signal output: 1920×1080@30fps ,Three Simultaneous Video Streams: Dual H.264 & Scalable M-JPEG
ONVIF-compliant Standard SDK is provided for easy integration with other video surveillance software. IP66 . PoE/12VDC/24VAC

2.0 Megapixel Starlight IR Network Dome Camera
Inbuilt 30X HD integrated camera module
VT231‐ A2 series is our newly introduced high definition infrared
network dome camera that supports 1920×1080@60fps HD. network video output. It adopts H.265/H.264/M‐ JPEG format
LED infrared lamps, infrared IR length 850nm, long night vision distance up to 200m
PTZ control easily via network and to configure detailed camera parameters settings

4 x 4MP 1/3” CMOS Sensor
H.264 addresses network and storage cost concerns
IP66 rated / Vandal Resistant IK10 / PoE+ / 12VDC
IFS16-M10-BT03 : Illustra Flex 4x 4MP Multisensor, 2.8mm, Indoor/Outdoor, IP66, IK10, TDN, TWDR

4 x 4MP 1/3” CMOS Sensor
H.264 addresses network and storage cost concerns
IP66 rated / Vandal Resistant IK10 / PoE+ / 12VDC
IFS16-M10-BT03 : Illustra Flex 4x 4MP Multisensor, 2.8mm, Indoor/Outdoor, IP66, IK10, TDN, TWDR

3.42 mm – 6.85 mm, motorized focus and zoom, P-Iris
Dedicated IR per sensor; 850 nm LEDs, 35 m (114.83 ft); Individually controllable
Rotate 90° right or left
IFS16-M10-OIA4 : Illustra Flex Gen4 16MP Dual Sensor, MFZ 3.42-6.85mm, Edge AI, TWDR, TDN w/IR, IP66/67, IK10

IPS08-P25-OI04 : Illustra Pro PTZ 8MP Gen4, Outdoor, 22x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC

IPS02-P24-OI04 : Illustra Pro PTZ 2MP Gen4, Outdoor, 42x Optical Zoom, 12 Digital Zoom, True D/N with IR, True WDR, IK10, IP66 PoE 802.3bt Type4/22-30VAC
